Silver/Silver Chloride Paste Screen Print Ink
Silver/Silver Chloride Paste
NanoChemazone provide a wide range of working electrodes Screen Printing Paste and Inks for all forms of electrochemical analysis including cyclic voltammetry, chrono-amperometry and potentiometric methods.
The paste is highly thixotropic which gives it very good definition on printing.
Product Benefits:
- Low coefficient of variation (CV%).
- This product has no significant hazardous materials.
- It gives excellent electrochemical performance with good reversibility when using cyclic voltammetry
- high adhesion to ceramic substrates.
- Stable electrical properties on repeat firing.
- Suitable for fine line printing.
MF: |
Ag/AgCl |
Chemical Name: |
Silver/Silver Chloride Paste
|
Purity: |
>99.99% |
Molecular Weight |
143.32 g/mol |
Product Number: |
NCZ-SPI-104 |
Form: |
Ink/Paste |
CAS Number: |
7783-90-06 |
Storage |
15ºC to 25ºC |
Substrate |
Suitable for Polyester, PVC, Polycarbonate or ceramic, zirconia |
Solids Content at 130°C |
39 – 41% (Customizable) |
Viscosity
Haake RS1 C20/2º TiL at
230 sec-1 at 25°C. |
2.7 – 3.3 Pa s (Customizable) |
Pack Size: 10 mL, 25 mL, 50 mL and 100 mL
Bulk Pack Size: 250 mL, 500 mL and 1000 mL
