Insulating Paste Screen Print Ink
Insulating Paste
NanoChemazone provides a wide range of working electrodes Screen Printing Paste and Inks for all forms of electrochemical analysis including cyclic voltammetry, chrono-amperometry and potentiometric methods.
The paste is highly thixotropic which gives it very good definition on printing. screen printable polymer dielectric, suitable for defining electrode areas and forms a protective layer over the electrode tracking during immersion of the electrode.
Product Benefits:
- Low coefficient of variation (CV%).
- This product has no significant hazardous materials.
- It gives excellent electrochemical performance with good reversibility when using cyclic voltammetry.
- high adhesion to ceramic substrates.
- Stable electrical properties on repeat firing.
- Suitable for fine line printing.
Special Features of Dielectric Paste:
- This product is a screen printable white dielectric paste, designed for use with electrochemical sensors.
- Excellent Opacity.
- Excellent Insulation.
- Long screen life
- The formulation is designed for maximum flexibility
Product Name: |
Insulating Paste |
Purity: |
>99.99% |
Product Number: |
NCZ-SPI-108 |
Form: |
Ink/Paste |
Storage |
15ºC to 25ºC |
Substrate |
Suitable for Polyester, PVC, Polycarbonate or ceramic, zirconia |
Solids Content at 130°C |
51-54 % (Customizable) |
Viscosity
Haake RS1 C20/2º TiL at
230 sec-1 at 25°C. |
12.00 – 16.00 Pa s
(Customizable) |
Pack Size: 10 mL, 25 mL, 50 mL and 100 mL
Bulk Pack Size: 250 mL, 500 mL and 1000 mL
